Pioneer DJ

DDJ-FLX6-GT Legacy

DJ Controller · Released 2022

Four-channel USB-powered controller with Merge FX, Jog Cutter, and large jog wheels with track-position displays.

Overview

Mixer channels
4
Built-in audio interface
Yes
Operation mode
Computer / mobile
Controller layout
Club / standard
Jog / platter type
Capacitive-touch
Master output class
Unbalanced
Standalone playback
No
Standalone mixer
No
rekordbox Serato DJ Traktor VirtualDJ djay

Specifications

Units:

“-” means no value is recorded. Conversions (≈) are approximate.

Software & operation

Official software support

rekordbox

Official support
Yes
Hardware unlock
Yes

Serato DJ

Official support
Yes
Hardware unlock
Yes (Pro)
Included license
Yes (Serato FX Pack; Serato Pitch ’n Time DJ)

Traktor

Official support
Yes (paid license required)
Hardware unlock
-

Official Traktor Pro 3 mapping; a separate software license or subscription is required.

VirtualDJ

Official support
Yes (paid license required)
Hardware unlock
-

djay

Official support
Yes
Hardware unlock
-

Legacy controller: official support may be limited to older software versions and operating systems.

About software support & licenses →

Operation mode
Computer / mobile
Standalone playback
No
Built-in audio interface
Yes

Decks & mixer

Mixer channels
4
Deck control
4
Physical deck sections
2
Controller layout
Club / standard
Standalone mixer
No
DVS
No
Channel gain / trim knobs
Yes
EQ bands per channel
3
Per-channel filter
Yes
User-replaceable crossfader
No

Connections

Master output
  • 2 × RCA (unbalanced)
Master output class
Unbalanced
Booth output
  • 2 × RCA (unbalanced)
Headphones
  • 1 × 6.35 mm stereo
  • 1 × 3.5 mm stereo
Microphone inputs
  • 1 × 6.35 mm (contacts unspecified)
Line / phono inputs
None
Aux input
None
Computer USB
  • 1 × USB-B
Dual-computer support
No
DMX output
No
Built-in speakers
No
Connection exceptions
One 6.35 mm microphone socket. Pioneer’s manual (DRI1673B) lists it as TRS, while its launch specifications list TS.

Jog wheels & transport

Jog / platter type
Capacitive-touch
Jog / platter diameter
206 mm
Jog display
Yes Playhead position
Feel / tension adjustment
No

Performance & FX

Pads per deck
8
Dedicated stems controls
No
Hardware FX
No
FX controls
  • Knobs / buttons
Extra features
  • Merge FX
  • Jog Cutter
  • Sample Scratch

Display & media

Main display
No display
Touchscreen technology
No touchscreen
Media / storage
None
Network / wireless
None

Size & power

Width
676 mm
Depth
345.7 mm
Height
68.7 mm
Weight
3.8 kg
Power source
USB bus-powered

Audio specifications

Audio resolution (bit)
24
Sample rate (kHz)
44.1
Frequency response
20 Hz–20 kHz
Signal-to-noise ratio (dB)
104
Master out THD (USB, %)
0.004
Audio note
USB path; S/N at rated output, A-weighted; THD measured over 20 Hz–20 kHz.

Notable included items

Notable included items
  • USB cable
  • Serato FX Pack
  • Serato Pitch ’n Time DJ

Manual, firmware & drivers

User manual ↗ Firmware & drivers ↗
