AlphaTheta

DDJ-GRV6

DJ Controller · Released 2024

Four-channel club-layout controller with 206 mm jogs, Groove Circuit, dedicated performance pads and dual USB-C ports.

Overview

Mixer channels
4
Built-in audio interface
Yes
Operation mode
Computer / mobile
Controller layout
Club / standard
Jog / platter type
Capacitive-touch
Master output class
Balanced + unbalanced
Standalone playback
No
Standalone mixer
No
rekordbox Serato DJ VirtualDJ djay

Specifications

Units:

“-” means no value is recorded. Conversions (≈) are approximate.

Software & operation

Official software support

rekordbox

Official support
Yes
Hardware unlock
Yes

Serato DJ

Official support
Yes
Hardware unlock
Yes (Pro)

VirtualDJ

Official support
Yes (paid license required)
Hardware unlock
-

djay

Official support
Yes (paid license required)
Hardware unlock
-

About software support & licenses →

Operation mode
Computer / mobile
Standalone playback
No
Built-in audio interface
Yes

Decks & mixer

Mixer channels
4
Deck control
4
Physical deck sections
2
Controller layout
Club / standard
Standalone mixer
No
DVS
No
Channel gain / trim knobs
Yes
EQ bands per channel
3
Per-channel filter
Yes
User-replaceable crossfader
No

Connections

Master output
  • 2 × 6.35 mm TRS (balanced)
  • 2 × RCA (unbalanced)
Master output class
Balanced + unbalanced
Booth output
  • 2 × RCA (unbalanced)
Headphones
  • 1 × 6.35 mm stereo
  • 1 × 3.5 mm stereo
Microphone inputs
  • 1 × 6.35 mm TRS
Line / phono inputs
None
Aux input
None
Computer USB
  • 2 × USB-C
Dual-computer support
No
DMX output
No
Built-in speakers
No

Jog wheels & transport

Jog / platter type
Capacitive-touch
Jog / platter diameter
206 mm
Jog display
Yes
Jog display technology
LED
Feel / tension adjustment
No
Tempo slider travel
60 mm

Performance & FX

Pads per deck
8
Velocity-sensitive pads
Yes
Pad backlighting
RGB
Dedicated stems controls
Yes
FX controls
  • Knobs / buttons
Extra features
  • Groove Circuit
  • Drum Swap
  • Drum Roll / Trans
  • Drum Release
  • Capture
  • Smart Rotary Selector

Display & media

Main display
No display
Touchscreen technology
No touchscreen
Media / storage
None
Network / wireless
None

Size & power

Width
711.4 mm
Depth
375.9 mm
Height
75.7 mm
Weight
4.6 kg
Power source
USB bus / AC adapter AlphaTheta spec table: DC 9V/3A via a USB-C power adapter, or DC 5V/1.5A via USB bus power — not a barrel-style AC adapter.

Audio specifications

Frequency response
20 Hz–20 kHz
Signal-to-noise ratio (dB)
104
Master out THD (USB, %)
0.003
Audio note
USB path.

Notable included items

Notable included items
  • USB-C cable
  • Overlay sheet

Manual, firmware & drivers

User manual ↗ Firmware & drivers ↗
