AlphaTheta

XDJ-AN

DJ Controller · Released 2026

Two-channel all-in-one with 7-inch touchscreen, USB-C storage, streaming and cloud playback, Wi-Fi, Bluetooth audio and SonicLink.

Overview

Mixer channels
2
Built-in audio interface
Yes
Operation mode
Standalone / computer
Controller layout
Club / standard
Jog / platter type
Capacitive-touch
Master output class
Balanced + unbalanced
Standalone playback
Yes
Standalone mixer
No
rekordbox Serato DJ djay

Specifications

Units:

“-” means no value is recorded. Conversions (≈) are approximate.

Software & operation

Official software support

rekordbox

Official support
Yes
Hardware unlock
Yes

Serato DJ

Official support
Yes
Hardware unlock
Yes (Lite)

Serato DJ Pro requires a subscription.

djay

Official support
Yes (paid license required)
Hardware unlock
-

About software support & licenses →

Operation mode
Standalone / computer
Standalone playback
Yes
Built-in audio interface
Yes
Onboard platform
rekordbox

Decks & mixer

Mixer channels
2
Deck control
2
Physical deck sections
2
Controller layout
Club / standard
Standalone mixer
No
DVS
No
Channel gain / trim knobs
Yes
EQ bands per channel
3

Connections

Master output
  • 2 × XLR (balanced)
  • 2 × RCA (unbalanced)
Master output class
Balanced + unbalanced
Booth output
None
Headphones
  • 1 × 3.5 mm stereo
Microphone inputs
  • 1 × 6.35 mm TRS
Line / phono inputs
None
Aux input
None
Computer USB
  • 1 × USB-C
Dual-computer support
No
DMX output
No
Connection exceptions
Separate USB-C ports for storage, PC/Mac/mobile data, and power.

Jog wheels & transport

Jog / platter type
Capacitive-touch
Jog / platter diameter
132 mm
Jog display
No
Jog display technology
No display

Performance & FX

Pads per deck
8
Hardware FX
Yes
FX controls
  • Knobs / buttons
  • Screen controls

Display & media

Main display
Color
Main display size
≈ 178 mm
Touchscreen
Yes
Media / storage
  • USB-C storage
Network / wireless
  • Wi-Fi
  • Bluetooth audio input
  • Bluetooth audio output

Size & power

Width
638 mm
Depth
359.2 mm
Height
89.9 mm
Weight
5.2 kg
Power source
AC adapter Dedicated USB-C power input; separate from the storage and PC/Mac/mobile USB-C ports.

Audio specifications

Frequency response
20 Hz–20 kHz
Signal-to-noise ratio (dB)
112
Master out THD (USB, %)
0.003
Audio note
USB path.

Notable included items

Notable included items
  • AC adapter
  • Power cord

Manual, firmware & drivers

User manual ↗ Firmware & drivers ↗
